Model #DW2451WS/ADA

• Water softener adjusts the amount of salt used per wash to the hardness level of your water
• Cove's new advanced wash system drives three powerful spray arms, 45 spray jets, and a fine-mesh filter that removes food and grease and circulates clean water
• Every glass, dish, and utensil comes out spotless and dry thanks to the hot rinse and fan assist
• Whisper-quiet operation means you can keep the conversation flowing while running a load of dishes
• Quality and aesthetics meet in a striking stainless-steel interior with a clean, fastenerless design
• 12 wash cycles and 6 add-on options can be mixed and matched, allowing you to personalize cleaning to your needs
• Offers infinite interior variations to meet your dishwashing needs; height-adjustable middle rack and fold-down tines accommodate large pots and tall items
• Loading and unloading is easy with interior LED lights that aid in visibility
• Stainless or panel-ready, in handle or handleless designs, complement any décor and coordinate perfectly with other Sub-Zero and Wolf appliances
• Dishwasher disappears into the kitchen with hidden control panel and discreet status light
• With our convenient Owner's App, you can remotely start or monitor a cycle, receive alerts when rinse aid is low—even set up auto-replenishment
• Cove’s leak protection system offers peace of mind in the rare event of a leak. A conductivity sensor in the base of the unit will automatically stop a cycle in progress if it detects a leak

• Overall Dimensions: 23 5/8" W x 32 1/2" H x 23 1/4" D
• Door Clearance: 25"
• Sabbath Mode disables sounds and interior lights, and prevents changes in the state of the control display
• Sound Level: 41 dBA (Model and cycle/option dependent)
• Energy Star Certified
• Receptacle: 3-prong grounding-type
• Water Connection: 5' braided tubing with 3/8" female compression fitting
• Drain Connection: 5' (1.5 m) corrugated tubing
• Pressure: 30–140 psi
• Electrical Supply: 115 VAC, 60 Hz
• Electrical Service: 15 amp dedicated circuit
• Cord Length 6'

• 4 LED lights (2 sides; 2 top)
• 45 spray jets across 3 spray arms
• Four-stage, fine mesh filter
• Adjustable stemware rail
• Adjustable cup shelf
• Height-adjustable middle rack
• Easy-glide bottom rack
• Upper silverware rack
• One large utensil basket
• Fold-down tines on lower and middle racks
• Water softener
